Hydraulic Railway Ballast Cleaning Machine, Crawler Type
Key Specifications / Features
Model no.: WE-231007-HE-07
Hits: 8
As a hydraulic railway ballast cleaning machine producer, we offer crawler-type equipment weighing 8.5 tons. Our machines feature a ballast undercutter with a total weight of 600 kg and an effective working radius of ≥ 1500 mm, ensuring efficient ballast cleaning for railway maintenance.
Request a quote
Tags
Detail Information
The Shoulder Ballast Cleaning Machine stands as the optimal solution for enhancing the overall quality of ballast and railway infrastructure. By equipping excavators and backhoe loaders with a Rail Ballast Blaster, we can swiftly and effectively remove contaminated ballast rock from beneath the tracks.
Our Ballast Cleaner boasts a full 360° continuous rotation feature, providing operators with enhanced flexibility to work from either side of the tracks. This not only streamlines operations but also significantly enhances the management of spoil piles, granting operators increased flexibility and the ability to achieve maximum cutting speed and performance.
| Ballast tool equipment parameter | |
| Rotation angle of ballast Undercutter | ≥270° |
| Ballast chain line speed | ≥3.0m/s |
| Effective working radiu | ≥1500mm（Two-way access) |
| Rotation speed (sprocket rotation) | 150r/min |
| Completed ballast replacement distance per hour | ≥20m/h |
| Dimensions of Ballast Undercutter | 2500*900*900mm |
| Ballast Undercutter Total Weight | 600Kg |
| Dimensions | |
| (Length*width*height)Transport dimensions | 6100*2200*2650mm |
| Axle base | 2600mm |
| Track gauge | 1570mm |
| Width of crawler | 400mm |
| Min. ground clearance | 280mm |
| Tech performance and specification | |
| Machine weight | 8500kg |
| Engine model | YUCHAI |
| Rated power | 55KW |
| Rated speed | 2200r/min |
