Key Specifications / Features
Looking for a reliable supplier of crawler trackhoe excavators? Your search ends here! Our machines, boasting an operating weight of 7 tons and driven by a robust 58.8 kW engine, deliver exceptional performance. Featuring a maximum reach of 6350 mm and a tail swing radius of 1800 mm, these excavators excel in maneuvering. With a 0.25 m³ bucket, they're well-prepared for diverse tasks. Contact us today to explore our range of crawler trackhoe excavators and see how we can fulfill your requirements!
- Model no.: WE-230816-CE-01
- Hits: 6
- Categories: Crawler Excavators
- Tags: Crawler Digger , 7 Ton Excavators , Fully Hydaulic Excavators
Detail Information
Operating Weight: 7000 kg, 7 Tons
Engine Power: 58.8 kw
Tail Swing Radius: 1800 mm
Bucket Capacity: 0.25 m³
High Speed / Low Speed: 4.5 / 2.5 km/h
Max Digging Reach: 6350 mm
Max Digging Depth: 3570 mm
Max Digging Height: 6600 mm
Max Dumping Height: 4500 mm
Gradeability: 35 °/70%
| SPECIFICATIONS | |
| Range Of Operation | |
| Boom Length | 3300mm |
| Arm Length | 1850mm |
| Maximum Digging Reach | 6350mm |
| Maximum Digging Depth | 3570mm |
| Maximum Digging Force | 45KN |
| Maximum Digging Height | 6600mm |
| Maximum Dumping Height | 4500mm |
| Back-End Radius of Gyration | 1800mm |
| Dimensions | |
| Length*width*height) travel position | 5500*2100*2650mm |
| Distance From The arm to Rotate Machine | 3600mm |
| Axle base | 2060mm |
| Track Gauge | 1570mm |
| Width of Crawler | 400mm |
| Ground Clearance of Counterweight | 780mm |
| Min Ground Clearance | 280mm |
| Tech Performance And Specification | |
| Angle of Rotation | 360° |
| Machine Weight | 7000kg |
| Engine Model | YUNNEI4102 |
| Rated Power | 58.8KW |
| Rated Speed | 2200r/min |
| Hydraulic System Working Pressure | 20Mpa |
| Hydraulic System Flow | 140L/min |
| Variable Piston Pump | 72ml/r |
| (High Speed/Low Speed) | 4.5/2.5km/h |
| Grade Climbing Ability | 70%/35° |
| Volume of Bucket | 0.25m3 |
| Revolution Overdrive Pressure | 20Mpa |
| Full Circle Swinging Time | 5.5s |
| Fqt Fuel Quantity | ≥4L/h |
| Capacity of The Fuel Tank | 110L |
| Hydraulic Tank Capacity | 110L |
