Key Specifications / Features
Explore our available Backhoe Loaders for Sale, sourced directly from a trusted fabricator. These equipment offerings come equipped with a Heavy Duty Bucket and boast a capacity of 7 tons. With an engine power of 58.8 kW, they offer a maximum digging reach of 6400 mm and feature a tail swing radius of 1820 mm.
- Model no.: WE-230822-WE-01
- Hits: 2
- Categories: Wheeled Excavators
- Tags: 7 Ton Excavators , Wheeled Digging Machine , Fully Hydaulic Excavators
Detail Information
Operating Weight: 7000kg, 7 Tons
Engine Power: 58.8 kw
Bucket Capacity: 0.2 - 0.3 m³
Tail Swing Radius: 1820 mm
Walking Speed: 25 km/h
Grade Climbing ability: 30 °/58%
Max Traction Force: 45 KN
Max Digging Reach: 6400 mm
Max Digging Depth: 3300 mm
Max Digging Force: 45 KN
Max Dumping Height: 4860 mm
| Range of operation | |
| Boom length | 3300mm |
| Arm length | 1850mm |
| Max. digging reach | 6400mm |
| Max. digging depth | 3300mm |
| Max. digging force | 45KN |
| Max. dumping height | 4860mm |
| Back-end radius of gyration | 1820mm |
| Dimensions | |
| (Length*width*height) Transport dimensions | 5800*2100*2850mm |
| Axle base | 2400mm |
| Ground clearance of counterweight | 1060mm |
| Min. ground clearance | 285mm |
| Tech performance and specification | |
| Angle of rotation | 360° |
| Machine weight | 7000kg |
| Engine model | YUNNEI（National Stage III) |
| Rated power | 58.8KW |
| Rated speed | 2200r/min |
| Hydraulic system working pressure | 20Mpa |
| Hydranlic system flow | 110L/min |
| Metering gear pump | 2*25ml/r(Gear Pump) |
| Max. Traction force | 45KN |
| Walking speed | 25km/h |
| Grade climbing ability | 58%/30° |
| Tyre model | 7.50-16 |
| Volume of bucket | 0.2-0.3m3 |
| Swing overload pressure | 20Mpa |
| Full circle swinging time | 5.5s |
| Fuel quantity | ≥4L/h |
| Fuel tank capacity | 110L |
| Hydraulic oil tank capacity | 110L |
